APT-20/30+EPS
| Quantity: | |
|---|---|
The APT-20/30 Powered Stacker, designed by NOVELTEK, is the ultimate solution for efficient and safe material handling in demanding environments. Combining advanced features such as Electronic Power Steering (EPS) and an AC motor, this stacker enhances productivity while reducing operational costs. Whether you need to lift heavy loads, navigate tight spaces, or achieve higher lifting heights, the APT-20/30 excels with its robust design and customizable options.
Key Features of Our High Lift Pallet Truck
1. Energy-Efficient AC Motor
The APT-20/30 uses an advanced AC driving motor that improves energy efficiency by up to 30% compared to traditional DC motors. This motor is brushless, reducing maintenance costs and ensuring long-term reliability.
2. Smooth and Safe Handling with EPS
The Electronic Power Steering (EPS) system allows for easier maneuverability, even in tight spaces. The EPS steering arm can rotate up to 185 degrees, providing superior control with minimal effort. Additionally, when turning, the stacker's speed automatically reduces by 50% for safer operations.
3. Customizable Fork Options
APT-20/30 offers a wide range of customization options to meet specific needs. You can choose from various fork widths, fork lengths, and lifting heights, ensuring it fits seamlessly into your existing material handling workflows.
4. Reliable and Low Maintenance
With a carbon brushless design and advanced AC inverter control, the APT-20/30 Powered Stacker offers a smoother, quieter, and more stable operation. Additionally, the CANBUS system integrates low battery protection alarms, and trouble-coding functions for easier servicing.
5. High Lift Capacity
The APT-20 supports a lifting capacity of 2000 kg, while the APT-30 can handle up to 3000 kg, making these models suitable for a wide range of heavy-duty tasks, from pallet stacking to high-lifting in warehouses, factories, and distribution centers.
6. Long-Lasting Power
Equipped with a long-term traction battery, the stacker is designed for extended use in various settings. The 24V battery can be customized based on your operational needs, ensuring longer battery life and reduced downtime during charging.
7. Compact and Versatile Design
Despite its robust performance, the APT-20/30 remains compact, with a minimum turning radius that allows it to operate efficiently even in narrow aisles. The adjustable speed settings ensure that operators can match performance to specific tasks.
Product Specifications
Feature | APT-20 | APT-30 |
Load Capacity | 2000 kg | 3000 kg |
Fork Width | 600 mm | 600 mm |
Fork Length | 1150 mm | 1150 mm |
Max Lift Height | 4000 mm | 4000 mm |
Min Fork Height | 83 mm | 83 mm |
Travel Speed (Empty) | 6.0 km/h | 6.0 km/h |
Travel Speed (Loaded) | 5.5 km/h | 5.5 km/h |
Turning Radius | 1696 mm | 1896 mm |
Battery Capacity | 180 Ah 24V | 240 Ah 24V |
Drive Motor Power | 1.6 kW | 1.6 kW |
Optional Customizations:
Fork Width: 470 mm, 520 mm, 685 mm
Fork Length: 1000 mm, 1300 mm, 1450 mm
Battery Capacity: Custom options available
Fork Inner Width: 90 mm, 140 mm, 305 mm
Who Can Benefit from Our Stacker Pallet Truck
The APT-20/30 is ideal for industries and businesses that require reliable, efficient, and safe material handling. It is commonly used in:
Warehouses and Distribution Centers: For lifting and stacking heavy pallets.
Manufacturing Plants: Ideal for handling materials in high-intensity production environments.
Retailers and Wholesalers: Perfect for moving and organizing bulk inventory.
Construction and Logistics: Efficient for stacking and organizing materials in tight spaces.
Why Choose NOVELTEK?
With over 30 years of experience, NOVELTEK excels in providing high-performance material handling solutions. Our APS-15/20 Powered Stacker combines cutting-edge AC motor technology and Electronic Power Steering (EPS) for unmatched efficiency and reliability. We offer customizable options to meet specific operational needs, ensuring the perfect fit for your business. Certified for quality and safety with CE and ISO 9001, NOVELTEK products are built to last. Backed by a global network and localized service, we guarantee prompt delivery and responsive support to keep your operations running smoothly.
Contact Us
For more information about the APT-20/30+EPS Powered Stacker, or to discuss your specific material handling needs, please don't hesitate to get in touch with our sales team. Let NOVELTEK help you optimize your warehouse operations and improve your material handling efficiency today!
