APT-50/70 AC+EPS
| Quantity: | |
|---|---|
Load capacity： (AC SYSTEM)(5.0 TONS)(HEAVY DUTY)
ADVANCED POWERED PALLET TRUCK
LED MDI-CAN multifunctional indicator has many internal functions: Indication of battery’s state of charge. Operating hour meter. With CANBUS system, low battery protection alarm and shows all trouble coding for easy service use.
EPS Steering Arm. (Electronic Power Steering) Steering Arm can work in 185 degree total arc for extra convenience.
With AC drive motor can save electricity efficiently by 30% and carbon brushless, easy maintenance.
Powerful Traction Battery
With bright colored coating composed of a detailed surface treatment, anti-rust primer, and lead-free PU baked enamel painting.
Key Features:
Powerful Electric Drive System: Featuring an advanced AC drive motor, the APT-50/70 saves electricity efficiently, reducing energy consumption by up to 30%.
Electronic Power Steering (EPS): Enjoy smooth and effortless maneuvering with the EPS system, which provides precise control with a 185-degree steering arm for easy operation.
Heavy-duty Capacity: The APT-50 offers a rated capacity of 5,000 kg, while the APT-70 can handle up to 7,000 kg, making it suitable for handling large, heavy loads.
Durable & Corrosion Resistant: Built with a high-quality, bright-colored coating that includes anti-rust and corrosion-resistant materials, ensuring long-lasting durability in tough environments.
Enhanced Safety: Equipped with a powerful traction battery and electromagnetic spring pressure parking brake for added safety during operation.
Product Specifications
APT-50/70 Power and Performance
The APT-50 and APT-70 models are engineered for superior performance in industrial applications. Their high-capacity AC motors, low-maintenance design, and cutting-edge electronic features make them the go-to powered pallet trucks for large-scale operations.
Feature | APT-50 | APT-70 |
Rated Capacity | 5000 kg | 7000 kg |
Load Center | 600 mm | 600 mm |
Lifting Speed | 8.0 sec | 7.0 sec |
Lowering Speed | 9.0 sec | 9.0 sec |
Travel Speed | 5.5 km/h | 6.0 km/h |
Grade Ability | 4.5% | 4.0% |
Weight (without battery) | 1000 kg | 1570 kg |
Battery | 240 Ah (24V) | 240 Ah (24V) |
Battery Charger | 40A (24V) | 60A (24V) |
Motor Power | 1.6 kW | 1.6 kW |
Lift Motor Power | 2.5 kW | 2.5 kW |
Steering Motor Power | 0.5 kW | 0.5 kW |
Ergonomics and Design
With a focus on ease of use and safety, the APT-50/70 powered pallet truck features a user-friendly, ergonomic design, which enhances operator comfort during long shifts. The adjustable steering arm ensures that operators can easily steer the unit, even in tight spaces.
Compact Size: Despite its heavy-duty capabilities, the APT-50/70 features a compact design that allows it to navigate narrow aisles and tight spaces with ease.
Comfortable Steering: The EPS steering system allows for a 185-degree turning radius, which enhances maneuverability and minimizes operator fatigue.
Efficient Battery Usage and Sustainability
Equipped with a powerful traction battery, the APT-50/70 can operate for extended periods without requiring frequent recharging. The AC drive motor helps reduce energy consumption, while the advanced CANBUS system alerts the operator to any battery-related issues, promoting optimal battery performance and longevity.
Energy Saving: The AC motor can save up to 30% more energy compared to traditional DC motors.
Battery Efficiency: Designed for long operating hours, the battery-powered system ensures fewer interruptions in your workflow, contributing to higher productivity.
Advanced Safety Features
Anti-Rust and Corrosion Resistance: The unit is coated with a special corrosion-resistant material, ensuring it holds up well under harsh conditions, including exposure to moisture and chemicals.
Parking Brake System: The electromagnetic spring pressure parking brake ensures secure stopping when not in use.
LED Multifunctional Display: The LED MDI-CAN indicator provides real-time data, including battery status and operating hour meter, ensuring that operators can track the truck's performance at a glance.
Dimensions and Specifications
Dimension | APT-50 | APT-70 |
Overall Length | 1650 mm | 1987 mm |
Fork Length | 1150 mm | 1150 mm |
Fork Width | 160 mm | 160 mm |
Overall Height (with lift) | 1470 mm | 1530 mm |
Minimum Fork Height | 85 mm | 85 mm |
Turning Radius | 1450 mm | 1645 mm |
Why Choose APT-50/70 Powered Pallet Truck?
1. High Performance: With a strong AC motor and advanced technology, the APT-50/70 ensures efficient material handling with high load capacities.
2. Cost-Effective: Save on maintenance and operating costs due to the durable construction and efficient battery use.
3. Versatile Use: Perfect for warehouses, logistics companies, and factories where heavy-duty material handling is required.
4. Improved Productivity: The easy-to-use design, coupled with powerful features like the EPS system, increases operational efficiency and reduces downtime.
If you are looking for a reliable, high-capacity powered pallet truck that can meet the demands of your warehouse, the APT-50/70 AC+EPS is the ideal choice. Contact us today to request more information or to place an order.
